Magewell Pro Convert for NDI® to AIO
The Magewell Pro Convert for NDI® to AIO uses NewTek’s royalty-free NDI® protocol for decoding and transmission. It converts your 1080P60 Full NDI, NDI | HX, NDI | HX2, RTSP, HTTP, HLS, RTMP Pull/Push and MPEG-TS via UDP/SRT/RTP protocols to SD/HD/3G-SDI or HDMI output signal. These streams can be captured from all compatible software and systems on the same network, regardless of physical distance, ensuring high-quality, low-latency, IP-based live production experiences that are superior to traditional live production solutions.
Key features:
Link
Output interfaces
- 3G SDI
- HDMI 1.4
- USB interface
- 5V / 2.1A power supply
- USB RNDIS / ECM
- Network Interface
- 10/100/1000 Mbps Ethernet
- IEEE 802.3af PoE
Control buttons
- MENU: Press to display the menu or cycle through the options
- SELECT: Press to display menu, enter current option or confirm selection
- 16-Position Rotary Switch: Set board index from 0 to F.
Decoding functions
- Support decoding 1080p60 full NDI, NDI | HX, NDI | HX2, RTSP, HTTP, HLS, RTMP Pull / Push and MPEG-TS over UDP / SRT / RTP protocols
- Simultaneously decode and output HDMI and SDI signals
- Support for H.264 / H.265 video decoders
- Support for AAC / MP3 audio decoders
Firmware
Upgradable firmware
Others
- LED indicators
- 2 year warranty
- 1 / 4-20 mounting hole
